General |
|
| Warranty | 3 years |
|---|---|
| LED colors | Single Color, White (6500K), Blue |
| LED type | 12 x 10 W White/24 x 3 W Blue |
| Fixture lumens | 6,100 |
| Beam angle | 110° |
| Electrical installation | Simple 2 wire connection |
| Operating voltage | 12 V/24 V |
| Operating voltage range | 10.5-31 VDC |
| Current consumption 12 V (max) | 4.9 A |
| Current consumption 24 V (max) | 2.4 A |
| Average power draw | 59 W |
| Construction | Marine bronze body with Borosilicate glass lens |
| Water and dust rating | IP68 |
Control Options |
|
| Direct power via on/off switch | |
|---|---|
Lighting Functionality |
|
| Functionality with direct power | Startup in model color |
|---|---|
| Applicable Controllers/Hubs | Direct power |
Mounting Dimensions |
|
| Mounting diameter clearance (with bezel) | 3.75" (95 mm) |
|---|---|
| Mounting depth clearance | 3.78" (96 mm) |
| Frontal protrusion (profile) | 0.7" (18 mm) |
| Mounting hole | 0.65" (16.5 mm) |
| Dimensions (width) | 3.75" (95 mm) |
| Dimensions (depth) | 4.48" (114 mm) |
| Dimensions (height) | 3.75" (95 mm) |
| Mechanical installation | Bonding required on non-conductive hulls (via connection on housing). Not suitable for conductive hulls, including wood and carbon fiber. |
White Single Color Light & External Driver
