General |
|
| Warranty | 3 years |
|---|---|
| Number of lights per Eclipse Comand Center/Expansion module zone | Dependent on connected lights |
| Electrical installation | Plug and play/hard-wired |
| Operating voltage | 12 V |
| Operating voltage range | 10-15 VDC |
| Current consumption 12 V (max) | 0.04 A (device only) |
| Average power draw | <0.5 W (device only) |
| Construction | Robust weatherproof ABS (flame retardant and halogen-free) |
| Water and dust rating | IP67 |
Control Options |
|
| Momentary switch | yes (via ECLIPSE Command Center) |
|---|---|
| Eclipse Command Center | |
| Compatible MFD | yes (via ECLIPSE Command Center) |
| Smart device | yes (via ECLIPSE Command Center) |
Mounting Dimensions |
|
| Dimensions (width) | 3.32" (84 mm) |
|---|---|
| Dimensions (depth) | 4.55" (116 mm) |
| Dimensions (height) | 1.53" (39 mm) |
| Mechanical installation | Screw fixings |
1 Zone
