General |
|
| Warranty | 3 years |
|---|---|
| LED colors | White (5000 K) |
| LED type | 20": 40 x 10 W - White 30": 60 x 10 W - White 40" 80 x 10 W - White 50" 100 x 10 W - White |
| Fixture lumens | 20": 15,000 30": 23,760 40": 31,680 50": 39,600 |
| Beam angle | Letterbox beam (vertical - horizontal) 20": 9°-20° 30": 9°-32° 40" 9°-45° 50" 9°-50° |
| Number of lights via direct power | Not limited |
| Number of lights per Eclipse Comand Center/Expansion module zone | 16 max (Vin and Gnd are supplied separately to Command Center/Expansion Module) |
| Number of lights per LUX light control module | 16 maximum |
| Electrical installation | 3 wire |
| Operating voltage | 10.5-31 VDC |
| Current consumption 12 V (max) | 20": 12.8 A 30": 19.3 A 40": 25.7 A 50": 32 A |
| Current consumption 24 V (max) | 20": 6.4 A 30": 9.6 A 40": 12.8 A 50": 16 A |
| Average power draw | 20": 154 W 30": 232 W 40": 308 W 50": 384 W |
| Construction | Powder coated aluminum body with Makrolon lens |
| Water and dust rating | IP68 |
Control Options |
|
| Direct power via on/off switch | |
|---|---|
| Momentary switch | yes (via ECLIPSE Command Center or LUX Control Module) |
| Eclipse Command Center | |
| EOS-LUX Command Center | |
| Compatible MFD | yes (via ECLIPSE Command Center or EOS-LUX Command Center) |
| Smart device | yes (via ECLIPSE Command Center or EOS-LUX Command Center) |
| EOS-LUX-SUPRA Display | yes (via EOS-LUX Command Center) |
Mounting Dimensions |
|
| Dimensions (width) | 20": 22.56" (573 mm) 30": 32.40" (823 mm) 40": 42.14" (1070 mm) 50": 51.80" (1315 mm) |
|---|---|
| Dimensions (depth) | 20": 2.83" (72 mm) 30": 2.83" (72 mm) 40": 2.83" (72 mm) 50": 2.83" (72 mm) |
| Dimensions (height) | 20": 3.78" (96 mm) 30": 4.37" (111 mm) 40": 5.20" (132 mm) 50": 6.23" (158 mm) |
| Mechanical installation | Stainless steel fixing brackets |
40"
