General |
|
| Warranty | 3 years |
|---|---|
| Sizes | 8"/10" |
| Physical dimensions (Height) | 8": 11.37" (289 mm) 10": 13.4" (340 mm) |
| Physical dimensions (Width) | 8": 12" (305 mm) 10": 10" (254 mm) |
| Physical dimensions (Depth) | 8": 13.23" (336 mm) 10": 15.86" (403 mm) |
| Weight | 8": 26.4 lbs (12 kg) 10": 38.2 lbs (17.3 kg) |
| Amplifier Power (RMS) | 8": 500 W short-term 10": 750 W short-term |
| Frequency response (Anechoic) | 8": 31-112 Hz (±1.5 dB) 10": 27-111 Hz (±1.5 dB) |
| Frequency response (Anechoic, -3dB) | 8": 29 Hz/119 Hz 10": 25 Hz/118 Hz |
| Frequency response (Anechoic, -10dB) | 8": 21 Hz/143 Hz 10": 21 Hz/143 Hz |
| Enclosure type | Sealed |
| Enclosure finish | Black ash or black gloss |
| Grille(s) included | |
| Power modes | Automatic (signal-sensing) |
Signal Processing |
|
| Unbalanced input(s) | Stereo or mono (two RCA jacks) |
|---|---|
| Speaker/High-level inputs | Stereo or mono (removeable plug) |
| Input grounding | Isolated or grounded |
| Level control | Variable, from full mute to +15 dB over reference gain |
| Filter mode(s) | Low-pass |
| Filter slope(s) | 24 dB/octave |
| Filter frequency range | 25 Hz-130 Hz |
| Filter defeat function | |
| Polarity | 0 or 180º |
| Phase | Variable, 0-280º, referenced to 80 Hz |
Parameters |
|
| Effective piston area (SD) | 8": 32.18 in² (0.0208 m²) 10": 48.71 in² (0.0314 m²) |
|---|---|
| Effective displacement | 8": 80 cu in (1.3 L) 10": 127 cu in (2.08 L) |
10" with Black Gloss Finish (d110- GLOSS)
