General |
|
| Weight | 320 g (11.3 oz) |
|---|---|
| Stack height | 12.2 mm (0.48") |
| Adjustable release tension | |
| Water rating | IPX7 |
| Maximum rider weight | 231.5 lbs (105 kg) |
| Cleat type | SHIMANO SPD-SL |
| Q-factor | 53 mm (55 mm with provided 2 mm washer) |
| Quick change pedal body | Compatible with all Rally 110/210 pedal bodies; 4 wrench flats |
| Pedal body materials | Carbon material based design |
| Force data | |
| Battery Type | rechargeable lithium-ion |
| Quick charge | 12 hours in 15 minutes of charging time (USB-C required) |
| Accuracy (+/-) | 1% |
| Battery life | up to 90 hours |
| Temperature compensation | |
| Oval chainring compatible | |
| Measurement location | spindle |
| Field calibration | |
| Communication | ANT+®, Bluetooth® and USB (USB-C compliant) |
| Pedal IQ™ Smart Calibration | |
| Travel mode | |
Garmin Connect™ |
|
| Garmin Connect™ compatible | |
|---|---|
Single-sensing Power Meter
