General |
|
| Unit size | 168 x 168 x 58.7 mm (6.6" x 6.6" x 2.3" ) |
|---|---|
| Weight | 1.7 lbs (770 g) |
| Operating voltage | 9.6 - 31.2 VDC |
| Water rating | IPX7 |
| Operating temperature | -25° C to +55° C (-13° F to 131° F) |
| Splitter connector | BNC |
VHF Features |
|
| AIS collision and MOB alarms | |
|---|---|
VHF Radio |
|
| Spurious response | 70 dB |
|---|---|
| Max antenna gain | 6 dBi |
AIS Transponder Features |
|
| AUX VHF splitter | |
|---|---|
| Anchor watch | |
| VHF/DSC support | |
| Remote station support | Cortex H1 (x5), Cortex H1P (x5) |
| Remote vessel monitoring | |
AIS |
|
| Class | SOTDMA Class B |
|---|---|
| Long range position reports (Msg 27) | |
| Frequency range | 156.025 – 162.025 MHz |
| AIS Sensitivity (20% PER) | -113 dBm |
| Adjacent channel selectivity | 80 dB |
| Intermodulation | 67 dB |
| Splitter insertion loss | RX 0 dB, TX -2 dB |
GNSS |
|
| Integrated GNSS receiver | |
|---|---|
| Constellations | GPS, GLONASS, BeiDou, Galilleo |
| Differential support | SBAS, AIS Msg 17 |
| Navigation rate | 10 Hz |
Sensors |
|
| NMEA 2000 Compatible | |
|---|---|
| NMEA 0183 Compatible | |
| Heading | 9-axial, accuracy: +/- 10°, updated rate: 10 Hz (max) |
| Barometer | update rate 1Hz max (averaged) |
| Battery voltage | measured at power input |
| External sensor inputs | 5 |
Audio |
|
| Supported functions | Voice alarms, VHF, hailer, horn |
|---|---|
| Max external speaker output power | 10 W, < 1% THD, 4 Ω |
| Max hailer loudspeaker output power | 30 W, 4 Ω |
Daily Smart Features |
|
| Mobile app | |
|---|---|
Tactical Features |
|
| Stealth Mode | |
|---|---|
Electrical Features |
|
| Compass-safe distance | 80 cm (31.5") |
|---|---|
Sonar Features |
|
| Power output | 5 W |
|---|---|
Networking & Connections |
|
| NMEA 2000® Gateway | AIS, GPS and MOB PGN output, gateway translations to/from NMEA 0183 |
|---|---|
| NMEA 0183 detail | 1 isolated NMEA 0183 port, AIS and GPS sentences, gateway translations to/from NMEA 2000, 4800/38400 baud |
| Control outputs | 2 |
| Wireless Connectivity | Access point for up to 5 handsets (max 10 devices total), simultaneous client mode, 2.4 GHz, 802.11b/g/n, integrated antenna, SMA-RP external antenna port (optional) |
| Cloud connectivity | LTE-Cat1 with 3G fallback (U.S., Canada), 3G (Europe, Asia), integrated SIM, integrated antenna, SMA-RP external antenna port |
| Wireless security | WPA2 Personal |
| External GNSS antenna connector | SMA |
| Ant connector | SO-239 (50 Ω) |
Hub with smartAIS® Transponder and Remote Vessel Monitoring
