$2,698.50
$8,995.00
$2,698.50
Subtotal: $2,698.50
10 customers are viewing this product

Free Shipping

Free standard shipping on orders

Free Returns

Learn More.
Specs

General
Operational temperature range -45° C to +70° C
Maximum operating altitude 55,000 ft

Physical
Installed height (including rack) 1.35" (34.3 mm)
Installed width (including rack) 6.30" (160.0 mm)
Installed depth to connector backshell 11.62" (295.1 mm)
Weight (unit only) 2.42 lbs (1.1 kg)
Weight (with install rack, connector kit, and configuration module) 3.05 lbs (1.4 kg)

Power Specifications
14 V Typical/Tx 0.6 A
14 V Maximum/Tx 0.8 A
28 V Typical/Tx 0.3 A
28 V Maximum/Tx 0.4 A

Performance
Minimum sensitivity level -90 dBm
Maximum range (line of sight) 300 nautical miles
DME channels 5 (with compatible avionics)
Nominal Transmit Power 250 watts

Interfaces
RS-232, HSDB, King Serial, Audio Out

Certifications
TSO-C66c DME/N
ETSO-2C66b DME/N Class 1
Shortdes
Digital Remote-mount DME Radio
GDM 450R

GDM 450R

$8,995.00 $2,698.50
GDM 450R
GDM 450R
GDM 450R
GDM 450R
GDM 450R

GDM 450R

$8,995.00 $2,698.50
