General |
|
| Transducer cable length | 20 ft |
|---|---|
| Dimension | 3.6'' x 5.9'' x 1.6'' (91.6 x 150.8 x 42.8 cm) |
| Weight | 0.5 lbs (230 g) |
| Water rating | IPX7 |
| Display Type | HVGA color |
| Display Size | 1.9'' x 2.9'' (4.9 x 7.3 cm); 3.5'' diag, (8.7 cm) |
| Display resolution | 480 x 320 pixels |
| Mounting Options | flush, tilt/swivel |
| Input | Keyed |
Maps & Memory |
|
| Waypoints/favorites/locations | 5000 |
|---|---|
| Track points | 50,000 |
| Tracks | 50 |
| Navigation Routes | 100 |
Sensors |
|
| GPS | |
|---|---|
| Has built-in receiver | |
| Receiver | Traditional: 50/77/200 kHz |
| Supports WAAS | |
Electrical Features |
|
| Power Input | 10 to 20 Vdc |
|---|---|
| Typical current draw | 0.23 A |
| Max current draw | 1.0 A |
| Power Consumption | 2.8 |
Sonar Features |
|
| Displays sonar | |
|---|---|
| Traditional sonar (dual frequency/beam) | Built-in |
| Frequency | Traditional: 50/77/200 kHzCHIRP (mid and high) |
| Transmit power | 200 W (RMS) |
| Bottom Lock (shows return from the bottom up) | |
| Water Temperature Log | |
Networking & Connections |
|
| 4-pin transducer ports | 1 |
|---|---|
Fishfinder Features |
|
| Split-screen zoom | |
|---|---|
| Fish Symbol ID (helps identify fish targets) | |
| Autogain technology (minimizes clutter; maximizes targets) | |
| Adjustable depth line (measures depth of underwater objects) | |
| A-scope (real time display of fish passing through transducer beam) | |
| Water temperature sensor included | |
| Depth range shading | |
With Dual-beam Transducer
